ITech IT8512C+ User Manual

Specifications
Copyright © Itech Electronic Co., Ltd. 64
Input
Impendance
1MΩ
Dimension
436.5mm*88.2mm*463.5mm
*1 The voltage/current input is no less than 10% FS
*2 The scope of read-back resistance is: (1/(1/R+(1/R)*0.02%+0.08),1/(1/R-(1/R)*0.02%-0.08))
*3 The voltage/current input is no less than 10% FS
*4 Ascending/descending slope: 10%-90% current ascending slope from 0 to maximum current.
*5 Minimum rise time: 10%-90% current rise time
Model
IT8516C+
Rated value
( 0~40 ℃)
Input voltage
0~120V
Input current
0~24A
0~240A
Input power
3000W
Minimum
operation
value
0.15V at 24A
1.5V at 240A
CV mode
Range
0.1~18V
0.1~120V
Resolution
1mV
10mV
Accuracy
±(0.05%+0.025%FS)
±(0.05%+0.025%FS)
CC mode
Range
0~24A
0~240A
Resolution
1mA
10mA
Accuracy
±(0.1%+0.1%FS)
±(0.1%+0.1%FS)
CR mode
*1
Range
0.05Ω~10Ω
10Ω~7.5KΩ
Resolution
16bit
Accuracy
0.02%+0.08S *2
0.02%+0.0008S
CP mode
*3
Range
3000W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Dynamic mode
Dynamic
mode
CC mode
T1&T2
120uS~3600S /Res:1 uS
Accuracy
10uS+100ppm
Rising/Falling
slope *4
0.001~0.25A/uS
0.01~2.5A/uS
Minimum rise
time *5
≒70uS
≒70uS
Measuring range
Readback
voltage
Range
0~18V
0~120V
Resolution
0.1 mV
1mV
Accuracy
±(0.025%+0.025%FS)
±(0.025%+0.025%FS)
Readback
current
Range
0~24A
0~240A
Resolution
1mA
10mA
Accuracy
±(0.1%+0.1%FS)
Readback
power
Range
3000W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Protection range
OPP
Protection
≒3000W
OCP
Protection
≒26A
≒260A
OVP
Protection
≒125V
OTP
Protection
≒85℃
