iTechworld 2000W - Remote Control

Remote Control
(Sold Separately)
Figure 7 - Optional Remote Control
A
Remote Control Main Switch
B
Fault LED Indicator
C
AC Output Indicator
D
Inverter Load Indicator
E
DC Input Power Indicator
F
Battery Capacity Indicator
A. Remote Control Main Switch
The main switch is used for turning ON or OFF the output of the
inverter. With the switch in the ON position, the AC Output
Indicator LED(C) will glow green to indicate 240VAC is being
produced.
B. Fault LED Indicator
Will illuminate/flash red when a fault is detected, the 240VAC
output will be turned off. Please refer to the troubleshooting
section.
