Nominal Voltage: 12.8v
C/20 Rating usable amps 10v: 105Ah
Short Circuit Protection: Yes
Optimum Temperature Range: +5 to +60°C
BMS Operational Temperature Range: -40 to 80°C
Safety Protection Isolator: 80°C
Recommended Charge Current: 20 - 50A
Maximum Charge Current: 100A
Recommended Charge Voltage: 14.4v
BMS Charge Cut Off Voltage: 15v
BMS Low Voltage Cut Off: 8.5-9v
Continuous Discharge: 150A (175A 5 mins)
Peak Discharge: 270A 5 sec
Life Cycles 80%: 2000 +
Life Cycles 50%: 5000 +
Life Cycles 30%: 8000 +
UL certified 1642
IP67 Rated Waterproof and dustproof
CE Certified
Rohs Certified
UN38.3 Certified
ISO 9001 Certified
ISO 1400 Certified
Dimensions (LxWxH): 330*173*215mm (225mm including
terminals)
Weight: 12kg
Terminal Type: M8
Case Material: ABS
