Butt Splice Connector BN6 for 6 AWG
For wire extensions, it is advisable to utilise soldered butt splice connectors. This
ensures minimal resistance in the connections. The optimal approach is to crimp
both ends of the connector, followed by soldering both sides of the connector.
Once the connection is secured, it is crucial to employ heat shrink tubing to
protect the connections and prevent any potential short circuits.
FUSE SPECIFICATIONS:
The iTECHBC25 is equipped with an inbuilt 240V AC input fuse, along with an
external 30A blade fuse.
The external fuse is replaceable if blown, it is essential to install all recommended
Source Fuse Size
Output 30A
this task. Failure to establish a secure connection could result in a short circuit,
