Eng-3
4.1– Monitor Buttons
1
M Menu Button
2
3
Down Button
: Press to display the OSD menu or enter sub-menus.
: Press to move down in the menus.
: Press to move up in the menus.
: Press to exit.
: Press to turn the monitor on/off.
Up Button
4
E Exit Button
5
Power Button
6
LED Indicator
: Changes colour according to status.
4 .2– Monintor Ports
4.
Product
Overview
Power Connector: Insert the power cable to supply power to the monitor.
HDMI Connectors: Insert one end of the HDMl cable into the computer's
HDMl output and connect the other end to the monitor's HDMI port.
DP Connector: lnsert one end of the DP cable into the computer's DP
output andconnect the other end to the monitor's DP port.
Audio Output: Insert the audio cable for output of audio signals.
