INTERCHANGEABLE BRACKET GRB (optional)
h) Install the Interchangeable Bracket in the REVERSE position if
the measured distance is not equal to distance B in the table.
Standard Reverse
- Always use the mounting bracket's topmost mounting
holes.
- Rotate the centring rings to adjust the bracket horizontally.
i) Mount the heater on the wall bracket.
j) Level the heater vertically by rotating the levelling foot in or out.
15
