ITL SERVICE MANUAL
B-43
Step 50
Fit Straight connection in the crankcase alongwith sealing washer
(18x24x1.5 cu)
Step 52
Fit Neck for screw on suction side of oil pump housing.
Using sealing ring (Cu)
Step 51
Fit the lubrication oil pump assy to Front Brg. Cap using bolt M10x130.
(Use 0.1mm shim to adjust Backlash if required.)Torque the bolt up to
3-4 kg m with torque wrench.
Step 53
Fit suction strainer to neck for screw and tight propnly
To Next Page
