MASTER
SLAVE
SINGLE
CANCEL SET
Setup of alternate operation period is allowed only in the master
UPS, specifying the master/slave alternate operation period;
(factory default: 7 days)
7 DAYS
30 DAYS 90 DAYS
180 DAYS
CANCEL
SET
IV. Buttons
For entering into menu, confirming parameter selection
and returning to upper-level menu.
ENTER button
For shifting between menu items of the same level and
selecting parameters, i.e., crosswise circling.
CIRCLE button
When the UPS is supplying power through inverter,
pressing and holding this button for 1 second can stop
the inverter output (i.e., turn off the inverter).
OFF button
When the UPS is supplying power through bypass,
pressing and holding this button for 1 second can start
the inverter output (i.e., turn on the inverter); when the
UPS is supplying power through inverter, which obtains
power from rectifier, pressing and holding this button for
4 seconds can perform manual battery test; when the
UPS is giving audible alarm, pressing this button can
silence the alarm sound.
ON/SILENCE
button
UsageButton
8 Chapter 1 Product Introduction
E1-20010916-C-1.0
