R50 Blue Bar 5101171 Rev. L

TrueAC Power Supply

Part Number 4010442 4010443 4010604

4010605

Input Power Rating 120 VAC 60 Hz 230 VAC 50 Hz

120 VAC

50/60 Hz

230 VAC 50/60

Output Voltage 7 kV AC

Output Current 3.0 mA max, 5.0 mA short circuit

Temperature 105˚F (40˚C) max, ambient

Dimensions 5.5”L x 3.9”W x 4.5” H 8.6”L x 4.9”W x 4.5” H

Weight 6 lbs 6 lbs

High Voltage Connector Two screw-in type connectors Four screw-in type connectors

Figure 1. R50 Blue Bar Overview and Dimensional Drawing
