ITW SIMCO ION 4010442 User Manual

5
R50 Blue Bar 5101171 Rev. L
3. SPECIFICATIONS
R50 Blue Bar
Operating Voltage R50-8,000 VAC max, 50/60 Hz
Ionizing Pin Current R50-48 mA with 7200 VAC applied voltage, short circuit
Operating Temperature 176°F (80°C) max
Humidity 70% RH max, no dewing permissible
Dimensions 5/8”W x 1 1/4”H x Overall Length (OL) (see Figure 1)
Weight 0.5 lb/ft
Enclosure Glass-fiber-reinforced plastic (GRP)
Encapsulation Material Polyurethane, UL-94 V-O
Installation Hardware Plastic slider and nylon bolts
“D” Power Supply
Part Number 4000074 (D167Q) 4000075 (D257Q)
Input Power Rating 120 VAC 60 Hz 230 VAC 50/60 Hz
Output Voltage 7 kV AC
Output Current 3.0 mA max, 5.0 mA short circuit
Temperature 105˚F (40˚C) max, ambient
Dimensions 5.8”L x 4.0”W x 3.4” H
Weight 7 lbs
High Voltage Connector Two screw-in type connectors
“N” Power Supply
Part Number 4002321 (N167) 4002337 (N257) 4002322 (N267)
Input Power Rating 120 VAC 60 Hz
230 VAC 50 Hz
230 VAC 60 Hz
Output Voltage 7 kV AC
Output Current 3.0 mA max, 5.0 mA short circuit
Temperature 105˚F (40˚C) max, ambient
Dimensions 8.6”L x 4.9”W x 4.5” H
Weight 7 lbs
High Voltage Connector Four terminal block connections

ITW SIMCO ION 4010442 Specifications

General

Brand	ITW
Model	SIMCO ION 4010442
Category	Power Supply
Language	English
