Power Units (All Potted Models)
5200095 Rev C
Input Line Voltage Connections
The line cord must be connected to a power source of the correct voltage and frequency
as listed on the nameplate. For power unit with 120 or 240 VAC operating voltage, the
line cord is fitted with a plug. For power unit with a plug-less line cord, the following
connections is required:
N. America Wire Color International Wire Color Power Connection
Black Brown Live
White Blue Neutral
Green Green/Yellow Ground
If the static eliminating equipment is used on machinery, it is recommended that the line
cord of the power unit be connected to the machine “RUN” button. This enables the static
eliminating equipment to turn on and off with the machine. Some power unit is equipped
with ON/OFF switch with indicator.
CAUTION – Electrical Shock Hazard
Do not apply line voltage to power supply until all grounds and high voltage
connections of the equipment are completely installed.
ACHTUNG – Stromschlaggefahr
Verbinden Sie das Gerät nicht mit Nelzspannung, bevor alle Erdverbindungen
hergeslelll sind und alle Hochspannungsverbraucher angeschlossen sind.
ATTENTION – Danger d’éleclroculion
Ne pas meltre I’appareil sous tension avant de s’elre assuré que toules les mises a
la terre ont bien élé effectuees el que tous les appareils alimentes en haule tension
sont connectés.
High Voltage Connections for Standard Cable without Shielding
The high voltage cable on the static eliminating equipment may be shipped with the
spring-loaded high voltage connector affixed to it. If the connector is not installed on the
cable, it must be installed as described in Section 2. The power unit may have two or four
high voltage output terminals. Insert the spring-loaded high voltage connector into one of
the output terminal and finger-tighten the connector. Some static eliminating equipment
may have a separate green or green/yellow ground wire running along the high voltage
cable and must be connected to the ground terminal on the power unit. When routing the
high voltage cable, take precaution to prevent the high voltage cable from contacting any
conductive object by using the insulated cable supports provided. This will prevent high
voltage from arcing through the cable hence, causing cable burnout.
To Next Page
