C78 ENT M50 OVERVIEW
11
FEBRUARY 2003 EDITION
Injection system
Type pump - injectors (PDE)
System Bosch EDC MS 6.2
Maximum injection pressure bar 1600
Low temperature starting
Allowed, without external aids, down to °C -15
With electrical heating of intake air (optional), down to °C -25
With additional external heater, down to °C -30
Cooling
Closed coolant loop with sea water heat exchanger 50% mixture of water/Paraflu II or equiv.
Compliant with SAE J 1034 specification
Total coolant quantity liters ~ 40
Engine-only capacity liters ~ 15,5
Expansion tank standard
Forced circulation centrifugal pump
Flow rate at maximum rpm l/h 25200
Temperature regulation with thermostatic valve
Initial opening °C 68 ± 2
Maximum opening °C 78 ± 2
Sea water line forced circulation
Self-priming pump with neoprene impeller
Sea water pump height above sea level m ≤ 2
Max. pump capacity l/h 17500
Exhaust gas expulsion
Optional stack
Optional riser
Electrical system
Nominal voltage V dc 24
Self-regulated alternator:
voltage V dc 29
maximum current intensity A 90
Electrical starter motor:
nominal voltage V dc 24
absorbed electrical power W 4500
Recommended batteries capacity Ah ≥ 120
Current discharge at - 18 °C (SAE J 537) A ≥ 900
Drive train coupling
Flywheel diameter mm (inches) 355 (14)
Flywheel case type SAE 1
Weights
Dry without inverter Kg 900
