Iveco C78 ENT M50 User Manual

C78 ENT M50 OVERVIEW
9
FEBRUARY 2003 EDITION
Fuel economy – Pleasure use (A1)
Specific fuel consumption at maximum power g/kWh (g/HPh) @ rpm ≤ 218 (≤ 160) @ 2600
Specific fuel consumption at maximum torque g/kWh (g/HPh) @ rpm ≤ 200 (≤ 147) @ 1800
Lubricating oil consumption at maximum power g/h @ rpm ≤ 240 @ 2600
Gas Emissions
Compliance with Standard IMO MARPOL 73/78
ADDENDUM DIR. 94/25/EC
Sound Emissions
Maximum value of average level
for engines in basic configuration dB@A (measurement standard) 95 (ISO 3744)
Power Takeoffs (Optional)
3- throated Front Pulley for V belts
Basic diameter mm 202
Throat size mm 10
Power available to each belt kW (HP) ≤ 7,4 (≤ 10)
3-throated Front Pulley + Elastic Joint for Flange Coupling
Available torque Nm (kgm) ≤ 500 (≤ 51)
3-throated Front Pulley + Elastic Joint for Shaft Coupling
Available torque Nm (kgm) ≤ 400 (≤ 40,8)

Iveco C78 ENT M50 Specifications

General

Brand	Iveco
Model	C78 ENT M50
Category	Engine
Language	English
