IVT 12LR-N Service Manual

12LRN
5 – 4
[2] THE WIRE GUARD AND THE PLASM-
CLUSTER UNIT
1) Remove the 2 screws fixing the guard holder L and guard holder R.
2) Pull the left side of wire guard forward, and the hook of the guard
holder L will be unhooked.
3) Rotate the guard holder L in clockwise and remove.
4) Slide the wire guard L to the left and remove.
(left side)
(right side)
