IVT GS-XP12HR-N User Manual

GSXP12HRN
1 – 3
1.3. Installation demensions
1.3.1 Ceiling type
1.3.2 Floor type
1025
212
680
156
250 204
400
949
141
110
419
398
Length unit: mm
(unit size)
(unit size)
(unit size)
Hole for drainage pipe
(Ø 50mm)
Hole for refrigerant
and drainage pipe
(Ø 80mm)
Hole for refrigerant
and drainage pipe
(Ø 80mm)
Horizontal base line
Air outlet
(bolt pich)
(VIEW FROM FRONT)
(VIEW FROM CEILING)
680
220
110
141
156
212
250
1025
398419
949
400
(VIEW FROM TOP)
(unit size)
(unit size)
(unit size)
Hole for drainage pipe
(Ø 50mm)
Hole for refrigerant
and drainage pipe
(Ø 80mm)
Hole for refrigerant
and drainage pipe
(Ø 80mm)
Horizontal base line
Air outlet
(bolt pich)
Length unit: mm
(VIEW FROM FRONT)
