1 – 1
GSXP12HRN
Service Manual
CHAPTER 1. SPECIFICATION
[1] SPECIFICATION
1. GS-XP12HR-N / AE-X12FR-N
NOTE: The condition of star "✩" marked item are ‘ISO5151’ : 1994(E), condition T1, Voltage 230V.
MODEL INDOOR UNIT OUTDOOR UNIT
ITEMS GS-XP12HR-N AE-X12FR-N
Cooling capacity (Min. ~ Max.) kW 3.5 (0.9 - 4.0)
Heating capacity (Min. ~ Max.) kW 4.2 (0.9 - 6.0)
Moisture removal (at cooling) Liters/h 0.9
Electrical data
Phase Single
Rated frequency Hz 50
Rated voltage V 230
Rated current ✩
(Min - Max.)
Cool A 4.5 (1.2 - 6.0)
Heat A 4.7 (1.3 - 7.0)
Rated input ✩
(Min - Max.)
Cool W 900 (200 - 1300)
Heat W 970(180 - 1800)
Power factor ✩ Cool % 87
Heat % 90
Compressor Type Hermetically sealed rotary type
Model 5RS092XDF
Oil charge RB68A or FREOL ALPHA68M 320ml
Refrigerant system Evaporator Louver Fin and Grooved tube type
Condenser Corrugate Fin and Grooved tube type
Control Expansion valve
Refrigerant (R410A) 1000g
De-lce system Micro computer controled reversed systems
Noise level (at cooling) High dB(A) 43 49
Low dB(A) 35 -
Soft dB(A) 29 -
Fan system
Drive Direct drive
Air flow quantity (at cooling) High
m
3
/min.
12.9 30.2
Low
m
3
/min.
10.3 –
Soft
m
3
/min.
7.3 –
Fan Centrifugal fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 1/2", 1/4"
Drain piping mm O.D φ 20
Others
Safety device Compressor: Thermal protector
Fan motors: Thermal fuse
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Net dimensions Width mm 1025 780
Height mm 212 540
Depth mm 680 265
Net weight kg 31 37
