J.P. Instruments EDM-760 TWIN User Manual

Section 11 - Personalizing
Pilot Programming
You can program the automatic indexing rate (1-9 seconds or 0 = don’t
auto-index), the temperature display (°F or °C) and the EGT resolution (1
or 10°). To start the Pilot Programming Procedure, simultaneously hold
the STEP and LF buttons for five seconds. You will see the word
PROGRAM for two seconds and then the sequence shown in the chart
below. Tap the STEP button to advance to the next item in the list. Tap
the LF button to select alternate values of that item. The shaded areas in
the chart below pertain only to the Fuel Flow Option.
Select switch
Tap STEP
to advance
to the next
item
Tap LF to
sequence
through these
values Comments
T, F, A
PROGRAM
Stays on for two seconds.
T, F, A
FUEL ?
N
N Y Y—Yes—to change fuel status (see
page 31)
T, A
RATE 4
0 9  Indexing rate in the Automatic
Indexing Mode. Selecting 0, disables
the Automatic Indexing Mode.
T, A
OAT
F
OAT
F OAT
C
OAT readings in °F or °C.
Special mode: To calibrate the OAT
10°, hold both the STEP and LF
buttons simultaneously for five
seconds, which will proceed to the
next step.
Page 40 Engine Data Management
