Changing the Alarm Limits Procedure
STEP button sequences to next item
LF button sequences through
these values
Description
FAC? N FAC? Y
Restore factory defaults?
REV X.XX
Firmware rev. number (momentary)
ENG F ENG C
EGT CHT
Select F or C degrees for all engine temps.
You must also change the alarm limits to
°F or °C.
16.0 H BAT OR 30.5
H BAT
(10.0 H BAT 35.0
H BAT)
Battery high voltage limit, set in 0.5 volt
increments.
12.0 L BAT OR 24.0 L
BAT
(8.5 L BAT 30.0 L
BAT)
Battery low voltage limit, set in 0.5 volt
increments.
500 DIF
(30 DIF 990 DIF )
EGT difference limit, set in 10° increments.
450 H CHT (90 H CHT
500 H)
CHT high limit, set in 5° increments.
-60 CLD (-5 CLD
-200 CLD)
Cooling limit, set in 5°/min. increments.
1650 TIT (650 TIT
2000 TIT)
Also sets the maximum scale of the EGT
and TIT bar graph.
230 H OIL (40 H OIL
500 H OIL)
Oil temperature high limit, set in 5°
increments.
90 L OIL (10 L OIL
250 L OIL)
Oil temperature low limit set in 5°
increments
TIT2 -N TIT2 -Y
FOR OIL
If TIT2 probes are installed in place of oil
probes
CARB -N CARB -Y
FOR TIT
If carburetor probes are installed in place of
TIT probes
FUEL FLOW
IN GAL
GAL KGS LTR LBS
Selects the units in all measurements
where fuel quantity or fuel rate is
displayed
For Your Safe Flight Page 49
