J.P. Instruments EDM-930

FAA Approved Installation Manual for the Report No 908
EDM-900 and EDM-930 Page 33 of 56 Rev I
Primary Engine Data Management System Date 1-18-2013
1 Stainless Steel Screw Type Clamp
2 Ring Terminals
2 Screws and nuts 6-32 X 1/4
1 Fiberglass tube 3/8”X 5”
31.5 Component Parts list for CARB KIT 11900
1 P/N 400128, CARB probe
2 Ring Terminals
2 Screws and Nuts 6-32 X1/4"
1 Fiberglass tube 3/8”X 5”
31.6 Component Parts list for OIL temperature probe KIT 12400
1 P/N 400509 OIL probe
2 Ring Terminals
2 Screws and Nuts 6-32 X 1/4"
1 Fiberglass tube 3/8”X 5”
31.7 Component Parts list for Oil Pressure sensor KIT 12400
1 P/N 159936A
1 P/N 159961 Clamp, Loop Cushioned
1 P/N 174402 Connector Pack 3 Pin and Terminals
31.8 Component Parts list for Fuel Pressure Sensor KIT 14500 (only if required by POH)
1 P/N 159935A Fuel pressure sensor
1 P/N 159961 Clamp, Loop Cushioned
1 P/N 174402 Connector Pack 3 Pin and Terminals
31.9 Component Parts list for Kit 14800 Differential Fuel Pressure (only if required by POH)
1 P/N 159938 Fuel pressure sensor
1 P/N 159961 Clamp, Loop Cushioned
1 P/N 174204 Connector MS 3116F8-4S
31.10 Component Parts list for ampere shunt KIT 13000
1 P/N 159920 100 amp shunt
2 Ring Terminals
31.11 Component Parts list for Fuel Flow Transducer
1 fuel flow transducer, 201 or 231 PN 700900-1,-2
8 inches of 1.5”dia fire sleeve
1 3-pin connector housing
3 female pins
2 AN816-4-4 fittings Continental OR 2 AN816-6-4 fittings
31.12 Component Parts list for MAP sensor KIT 14400
1 P/N 159934A Fuel pressure sensor
1 P/N 159961 Clamp, Loop Cushioned
1 P/N 174402 Connector Pack 3 Pin and Terminals
31.13 Components Parts list for RPM sensor P/N depends on Magneto make and model
Bendix magneto -20,1200 P/N 420815-1
Slick magneto 4000 or 6000 P/N 420815-2
31.14 Weight and Balance Data
Indicator PN 790000(-A) EDM-900 2.0 Lbs
