J.P. Instruments EDM-930

FAA Approved Installation Manual for the Report No 908
EDM-900 and EDM-930 Page 46 of 56 Rev I
Primary Engine Data Management System Date 1-18-2013
+
Data out to GPS
Data in from GPS
IN
OUT
Main FF 700900-1, (201) -2 (231)
White 1
Gray 2
white 4
red 5
black 6
NC 9
White 12
10
11
13
White 14
Gray 15
Remote fuel flow alarm light (option)
IN
OUT
FF2
Power and ground connect
to pins 5 and 6 respectively
5 6
Right low
fuel switch
Left low
fuel switch
AMPS 2
159920
J4 (FF, GPS, AMP 2 )
Return FF 700900-1, (201) -2 (231)
Optional
Optional
optional
Serial communications
