12
P 1 7 0~99 65
Automatic presser foot sensor sensitivity setting (between the maximum
and minimum value of the 02C parameter
display)
P 1 8 1~120 35
Stitch balance for start back tacking No.1 (Pull in compensation)
P 1 9 1~120 20
Stitch balance for start back tacking No.2 (Release of compensation)
P 2 2 0~50 8
the interval of on and off gear when adding one stitch
P 2 4 0~1024 80
Trimming point of pedal
P 2 5 1~120 35
Stitch balance for end back tacking No.1
P 2 6 1~120 20
Stitch balance for end back tacking No.2
P 2 7 0~2 1
Mode of presser foot sensor （0-2）0：off，1：effective after trimming,
2：effective before and after trimming
P 3 0 0~31 0
Feed forward torque of motor: 0: normal functions
1-31: feed forward torque level
P 3 1 10~199 50
Trimming afterburner coefficient (motor
afterburner)
P 3 2 1~500 400
trimmer electromagnet full output time ms
