PLACE FURNACE
Review all instructions in the Planning Your
Installation section. Place the furnace in the
pre-selected location.
Refer to Page 17 in the Plan Your Installation
section. Make sure the furnace is level.
Furnace Casing
The furnace casing is shipped unassembled in a
carton attached to the furnace.
Slide side panels down over angled edges of the
black steel on the front and back of the furnace.
See Fig. 1
Place top panel over the front edge of the furnace
and set down over the side panels.
See Fig. 2
FIG. 1
FIG. 2
Installation
22
Big Jack Model Shown
