Jack SUPER JACK SJ125 - Wiring Diagram

BROWN/WHITE
BROWN
WHITE
BLACK (HIGH)
YELLOW (MED HIGH)
ORANGE (MED LOW)
RED (LOW)
GREEN
ROTATION-SHAFT END
CAP
COMMON
L1
L2
GROUND
INSULATE UNUSED SPEED
TAP LEADS SEPARATELY
BLACK
WHITE
BLACK
WHITE
WHITE
BLACK
BLACK
WHITE
CCW
CW
OPTIONAL 3 WIRE CONNECTION
BROWN/WHITE
BROWN
WHITE
SPEED TAP
L1
L2
CAP
INSULATE
CAP SIZE (if Reqd): 5MFD-370VAC
Wiring for 4-SPEED - 1/4 HP MOTOR (OPTIONAL)
29
Wiring Diagram
CAPACITOR
CAPACITOR
