Jack SUPER JACK SJ125 - Super Jack (SJ125)

Key No.
Part No. Description Qty
1 309 Jacket (Top) 1
2 304 Damper Plate w/Rod 1
3 303 Damper Control Rod 1
4 307 Jacket Side (Right) 1
5 302 Clean Out Plate Gasket 2
6 301 Clean Out Plate 2
7
10090332
10090102
Fire Door Assembly Screws (4) - Ash Door Screws (2) -
Draft Inducer Screws (3)
8 113 Fire Brick 9 x 4-½ x 1-¼ 19-1/2
9 119 Smoke Flap Assembly 1
10 117 Grate Fillers 2
11 105 Heavy Duty Cast Iron Grate 1
12 111 Draft Inducer Gasket 1
13 110 Draft Inducer 1
14 115 Fire Door Gasket 1
15 114 Fire Door w/Hinge Assembly 1
16
10090313
10104950 Door Bolts w/Nuts 4
17 107 Door Handle Assembly 2
18 101 Ash Door w/Hinge Assembly 1
19 102 Ash Door Gasket 1
20 104 Ash Pan 1
21 305 Fire Box Assembly 1
22 308 Jacket Side (Left) 1
23 10107000 Fan & Limit Control (Honeywell) 1
24 118 Poker Assembly 1
25 122 Conduit Clips 2
26 10110001 Junction Box 1
27 121 Transformer/Relay (Honeywell) 1
28 10111100 Conduit 2
29 10113200 Straight Conduit Connector 3
30 10113300 90 Degree Conduit Connector 1
* 10108700 Honeywell Interlock Relay 1
* 310-1 Insulated Front Panel (SJ125-C only) 1
* 311-1 Insulated Back Panel (SJ125-C only) 1
* 10108400 Honeywell Digital Thermostat 1
* Items not shown
SUPER JACK - SJ125
Exploded Views & Parts Lists
