Part No. Description Qty
1 205 Jacket (Top) 1
2 204 Jacket Side (Right) 1
3 113 Firebrick (9 x 4-½ x 1-¼) 19-1/2
4 119 Smoke Flap Assembly 1
5 117 Grate Fillers 2
6 105 Heavy Duty Cast Iron Grate 1
7 111 Draft Inducer Gasket 1
8 110 Draft Inducer 1
9 115 Fire Door Gasket 1
10 114 Fire Door & Fire Door Hinge 1
11
10090313
10104950
Door Bolts &
Nuts
4
12
10090332
10090102
Fire Door Assembly Screws (4) - Ash Door Screws (2) -
Draft Inducer Screws (3)
13 107 Door Handle Assembly 2
14 101 Ash Door & Ash Door Hinge 1
15 102 Ash Door Gasket 1
16 104 Ash Pan 1
17 201 Fire Box Assembly 1
18 203 Jacket Side (Left) 1
19 206 Two-Piece Baffle 1
20 10107000 Fan & Limit Control (Honeywell) 1
21 118 Poker Assembly 1
22 122 Conduit Clips 1
23 10110001 Junction Box 1
24 121 Transformer/Relay 1
25 10113200 Straight Conduit Connector 2
26 10111100 Conduit 2
27 10113300 90 Degree Conduit Connector 1
* 10108700 Honeywell Interlock Relay 1
* 210-1 Front Panel (BJ90-C only) 1
* 211-1 Back Panel (BJ90-C only) 1
* 10108400 Honeywell Digital Thermostat 1
* Items are not shown
BIG JACK - BJ90
Exploded Views & Parts Lists
49
