Jack ZB-A4F User Manual

11 / 14
P132
Pattern sewing max speed
2000 200~3000
P133
Step Z signal relative to 0mm
offset
-47 -999 ~999
P134
Step Z signal relative to 0mm
offset
1160 0 -9999
P161
Stitching needle length speed
compensation ratio
100 70-130
P162
Reverse stitching needle length
speed compensation ratio
100 70-130
P171
Stitching needle length
compensation ratio
100 70-130
P172
Reverse stitching needle length
compensation ratio
100 70-130
P173 Pause press foot height
9 1-13
P174 Tirm press foot height
9 1-13
P175 Press foot height adjust
0 -999~999
P177 Press down speed
300 50-1000
P179 Press up speed
400 50-1000
P181 Press height limit
13 0-13
P182 Stepmotor press up time
10 0-9999
P183
Stepmotor stitch act angle
length change
150 0-359
P184 Stepmotor keep current
28 1-50
P185 Stitch length keep time
0 0-10
P186
Stepmotor target location
adjust
6 0-30
P187 Stepmotor current limit
70 60-80
P193
1/2 stitch length key mode
change
0 0-5
0:1/2
1:1/4
2:1/8
3:back sew 1/2
4:back sew 1/4
5:back sew 1/8
P194 Start sew first stitch speed
800 0-3000
P195 Start sew second stitch speed
1500 0-3000
P196 Start sew third stitch speed
0 0-3000
P197 Stitch unit
0 0-1
0:mm 1:British systerm
P202 Bus voltage compensation
0 -30~30
