Jacobsen 67042 - Frame

52
> Change from previous revision
2
2
9
9
8
7
6
2
7
8
9
5
4
3
Serial Plate
1
TRI-KING
11.1 Frame
Gas Engine
Serial No. 67042-All
Item Part No. Qty. Description Serial Numbers/Notes
1
2811396 1 Frame
2 328133 4 • Bushing
3 3002170 4 • Bushing
4 365106 2 • Bushing
5 471216 1 • Grease Fitting
6 2811393 1 Column Assembly
7 400188 2 Screw. 5/16-18 x 1” Hex Head
8 445781 2 Nut, 5/16-18 Whizlock Flange
9 452006 2 Flat Washer, 5/16
