GB-NL-F-12
GB
SPECIFICATIONS
ENGINE SPECIFICATION
TYPE: Kubota 28KW (38HP) @ 3000 RPM, 4
cylinder (in line) vertical Diesel engine, 4
stroke, water cooled, 1498cc (91.44
cu.in) with 12V electric start.
Model: V1505-BBS-EC-1
Maximum Speed: 3000 ± 50 RPM (No load)
Idle Speed: 1500
RPM
Oil Sump Capacity: 6 litres (10.56 Imp.pints) (12.68 US pints)
Firing Order: 1, 3, 4, 2.
Fuel: No. 2-D Diesel fuel (ASTM D975)
ENGINE SPECIFICATION (TURBO)
TYPE: Kubota 34.7KW (46.5HP) @ 3000 RPM,
4 cylinder (in line) turbo-charged
vertical Diesel engine, 4 stroke, water
cooled, 1498cc (91.44 cu.in) with 12V
electric start.
Model: V1505-TE
Maximum Speed: 3000 ± 50 RPM (No load)
Idle Speed: 1500
RPM
Oil Sump Capacity: 6.4 litres (11.26 Imp.pints) (13.52 US
pints)
Firing Order: 1, 3, 4, 2.
Fuel: No. 2-D Diesel fuel (ASTM D975)
MACHINE SPECIFICATION
Speeds:
Cutting: 0 - 12km/h (0 - 7.5 mph) FORWARD
0 - 6.4km/h (0 -4 mph) REVERSE
Transport: 0 - 16km/h (0 - 8.5mph) FORWARD
Tyres:
Front - 26.5 x 14.00 - 12 4 ply rating turf
tread
Rear - 20 x 10.00 - 8 4 ply rating turf
tread
Pressures: All tyres1 kg/cm
2
(14p.s.i.)
Construction: Heavy duty formed steel chassis with
box section frame rails.
Transmission: Full time 4-wheel drive. Direct coupled
vaiable displacement pump to direct
coupled 29 cu in front, 21 cu in rear
wheel motors.
Brakes: Hydrostatic braking with mechanical type
band parking brakes, 260mm x 45mm
(10.25in x 1.75in) on front wheels.
Steering: Hydrostatic power steering, with
adjustable tilt steering wheel.
Cooling System
Capacity: 4litres (7 Imp. pints) (1.06 US gals)
Fuel Tank
Capacity: 45.4 litres (10 Imp. galls) 12 US galls
Hydraulic Tank
Capacity: 37.8 litres (8.3 Imp. galls) 10 US galls
DIMENSIONS
Width of cut: 2.5 metres (98in)
Overall width: (transport) 2.13 metres (84in)
Overallwidth: 2.6metres (104in)
Overall height: 1.4 metres (56in)
Overall length: 3.1 metres (122in)
Overall weight of machine: 1270kg (2800lb)
+ 100
- 0
+ 100
- 0
