GB-NL-F-14
GB
NOISE EMISSION
Conforms to the specification of Directive EEC 79/113, 84/558,
87/252, 88/180, 88/181.
Sound Power Level: 104dB(A) LWA (Bystander)
Sound Pressure Level: 85.7dB(A) LpA (Operator Ear
Level)
VIBRATION LEVEL
The machine was tested for whole body and hand/
arm vibration levels. The operator was seated in the
normal operating postion with both hands on the
steering mechanism. The engine was running and
the cutting device was rotating with the machine
stationary.
Hand / Arm acceleration level : 0.46 m/s
2
Whole body acceleration level
X axis : 0.014 m/s
2
Y axis : 0.027 m/s
2
Z axis : 0.020 m/s
2
RECOMMENDED LUBRICANTS
Engine oil: Should be to MIL-L-2104C or to A.P.I.
Classification CE grades and as given in the
table below:
Temperature Oil Viscosity
ABOVE 25°C (77°F) SAE 30
0°C to 25°C (32°F to 77°F) SAE 20
BELOW 0°C (32°F) SAE 10w
Hydraulic Oil: To A.P.I. Classification CE/SF grades
SAE 10w-30
Grease: Shell Darina R2 or equivalent.
CUTTING UNIT SPECIFICATION
General: Five 559mm (22in) rotary mulching decks
supported by equal ratio lift arms.
Drive: Fixed displacement hydraulic motors directly
coupled to cutting unit.
Control: Cutting unit lift lever with automatic shutoff and
safety interlock restart.
Construction: Heavy duty, welded pressed steel.
Suspention: Steerable floating head.
Cutting Blades:
Envirodeck
Patent pending twin blades. Lower blade
559mm (22in), upper blade 546mm
(21.5in)
Side Discharge
High Lift Blade
Height of cut: Adjustable in 6mm (0.25in) increments; no tool
required.
Rear roller: 102mm (4in) diameter smooth roller.
