Jacobsen Eclipse 322 User Manual

2 SPECIFICATIONS
en-10
2.4 BATTERY POWER MODULE ________________________________________________
To ensure the longest battery life possible, the batteries
are not shipped with the power module and must be
ordered separately. For optimum range and performance
use batteries that equal or exceed the Amp-hour rating
listed.
System Voltage............. 48 Volt DC
Batteries ...................... (6) 8 volt lead acid batteries.
Charger......................... 18 Amp, 48 Volt DC, input
voltage 85-265 Volt AC, 45-65
Hz. Three charging algorithms
Battery Filling System... Single connection used for
adding water to all 24 battery
cells simultaneously.
Recommended Battery:
Trojan T-890 battery is the Jacobsen recommended
battery for use in the Eclipse 322 mower.
Trojan T-890 batteries can be ordered from your
Jacobsen Dealer, or from any local battery dealer.
2.5 CUTTING UNITS: __________________________________________________________
Reel ................................3 Reels, 22 in. (55.9 cm) wide.
Reel Diameter.................5 in. (12.7 cm)
Blade Options ................. 7, 9, 11, or 15 blades
Cutting Width.................. 62 in. (157.5 cm)
Cutting Frequency .......... Variable, See Section 4.6
Height of Cut Range....... 1/16 to 7/16 in. (0.16 to 1.11 cm)
2.6 MOWER _________________________________________________________________
Tires................................ 18 x 10.5 - 8 tubeless
Pressure:
Front .........................16 psi (1.1 BAR)
Rear..........................20 psi (1.3 BAR)
Parking Brake .................Automatic, mounted on drive
motor
Drive Axle:
Differential Type........ Open
Ratio .........................19.626:1
Lubrication ................23 oz. (680 ml) Mobilfluid 424 or
SAE 30 wt.
Drive Motor..................... 48 Volt AC
Steering:
Type.......................... Electric Power Steering
Motor ........................ 48 Volt AC Chain Drive
Speed:
Mow ......................... 1 - 5 mph (1.6 - 8.0 kph)
Transport ................. 1 - 9 mph (1.6-14.5 kph)
Reverse .................... 1 - 4.0 mph (6.4 kph)
Battery Brand Battery Part Number
Trojan T-890
Length
in. (cm)
Width
in. (cm)
Height
in. (cm)
Weight
lbs. (kg)
5 Hr.
Rate
Amp-Hr
Volts
Qty
Req’d
10-3/8
(26.4)
7-1/8
(18.1)
10-7/8
(276.)
69
(31)
155 8 6
