SPECIFICATIONS 2
en-15
2.9 WEIGHTS AND DIMENSIONS ________________________________________________
Dimensions: Inches (cm)
Length - Grass Catchers On......................... 101 (256.5)
Height - Top of ROPS .................................. 79.3 (201.4)
Wheel Base..................................................... 52 (132.1)
Width - Mowing Position............................... 67.7 (172.0)
Width - Wheel.................................................. 59 (150.0)
Turning Radius................................................ 18 (45.7)
Weights: Lbs. (kg)
Working Weight Less Operator
62800 .......................................................... 1697 (770)
62801 .......................................................... 1661 (753)
62802 .......................................................... 1577 (715)
62803.......................................................... 1541 (699)
62804 and 62853........................................ 1665 (755)
62805 and 62851........................................ 1629 (739)
62825 and 62852........................................ 1629 (739)
62826 and 62854........................................ 1665 (755)
Mower with fuel tank empty
62802.......................................................... 1544 (700)
62803.......................................................... 1508 (684)
62804 and 62853........................................ 1627 (738)
62805 and 62851........................................ 1591 (722)
62825 and 62852........................................ 1591 (722)
62826 and 62854........................................ 1627 (738)
2.10 ACCESSORIES & SUPPORT LITERATURE_____________________________________
Contact your area Jacobsen Dealer for a complete listing of accessories and attachments.
Accessories
Traction Pedal Test Connector................................ 4225240
Field Test Kit ........................................................... 4222802
Orange Touch-up Paint (12 oz. spray)...................... 554598
Grass Catcher......................................................... 4214180
Fine Bristle Brush........................................................ 68536
Rear Roller Cleaner Brush.......................................... 62818
Quick Roll™ (Set of 3) (Requires 4211921)................ 68664
Spiker (Set of 3) (Requires 4211921).......................... 68665
Quick Roll™ or Spiker Mounting Kit.........................4211921
Traction Tire Kit........................................................... 62817
Turf Groomer 1/4” Spacing.......................................... 67966
Turf Groomer 1/2” Spacing.......................................... 67968
Vertical Mower (Set of 3)............................................. 67138
Dew Whip Holder........................................................ 62809
Tow Bar........................................................................62811
Premium Seat ............................................................. 62813
Clipping Deflector........................................................ 62814
ROPS Mounted LED Light Kit................................. 4214980
Discharger (Battery Units)......................................... 892857
Reels
TrueSet™ 7 Blade Reel ............................................. 62830
TrueSet™ 9 Blade Reel ............................................. 62831
TrueSet™ 11 Blade Reel ........................................... 62832
TrueSet™ 15 Blade Reel ............................................ 62833
Reel Conversion Kit ................................................ 4218680
Rollers
Grooved Front Roller...................................................68527
Solid Roller .................................................................68530
Grooved Front Roller (Steel)........................................68613
Grooved Front Roller (Aluminum)................................68614
High Cut Roller 15/16 in...............................................68634
Solid Tube Steel Roller with Scraper ...........................68641
Grooved Segmented Roller.........................................68673
Rear Roller Scraper...................................................338735
Solid Tube Rear Roller ............................................1004990
MagSystem™
Super Tournament MagSystem Kit..........................4188500
Tournament MagSystem Kit.....................................4158083
Support Literature
Safety & Operation Manual......................................4187720
Parts & Maintenance Manual...................................4187721
Diesel Engine Parts Catalog....................................4222980
Operator Training Video...........................................4222982
Service & Repair Manual.........................................4222983
CAUTION
Use of other than Jacobsen authorized parts and accessories may cause personal injury or damage to the
equipment.
!
