Jacobsen Eclipse 322 User Manual

LDU ERROR CODES 12
en-99
Throttle Sensor Error. Shut mower
off, then restart, making certain
traction pedal is in neutral. If fault
returns, mower must be towed back
to maintenance shed.
44 44 4
44 44 4
Reverse Alarm Test Failed. Shut
mower off, then restart. If fault
returns, mower must be towed back
to maintenance shed.
44 44 4
44 44 4
Mechanical Brake Test failed. Shut
mower off, then restart. If fault
returns, mower must be towed back
to maintenance shed.
44 44 4
44 44 4
Brake sensor error. Shut mower off,
then restart. If fault returns, mower
must be towed back to maintenance
shed.
44 44 4
44 44 4
Speed Sensor feedback error. Shut
mower off, then restart. If fault
returns, mower must be towed back
to maintenance shed.
44 44 4
Center switch has not reached cam
end within 6 seconds. Shut mower
off, then restart. If fault returns,
mower must be towed back to
maintenance shed.
44 44 4
The position error during the
calibration is greater than the error
window. Shut mower off, then restart.
If fault returns, mower must be towed
back to maintenance shed.
44 44 4
wheel angle and cam center switch
signal are not synchronized. Shut
mower off, then restart. If fault
returns, mower must be towed back
to maintenance shed.
44 44 4
LDU Error Code Description
Caution
LED
Alarm
Sounding
Engine
Stop
Traction
Stop
Mow Stop
On Off Yes No Yes No Yes No Yes No
TRACTION
FAULT 6211
STEERING
FAULT 6211
TRACTION
FAULT 6212
STEERING
FAULT 6212
TRACTION
FAULT 6213
STEERING
FAULT 6213
TRACTION
FAULT 6214
STEERING
FAULT 6214
STEERING
FAULT 7310
STEERING
FAULT 7320
STEERING
FAULT 7321
STEERING
FAULT 7322
