Jacobsen G-Plex III Parts And Maintenance Manual

96
NUMERICAL INDEX
PART NO DESCRIPTION PAGE ITEMPART NO DESCRIPTION PAGE ITEM
JACOBSEN G PLEX III Series: DN & DP
MAINTENANCE AND PARTS MANUAL
001921740 Hose, fuel, 30" 19 8
001925160 Clamp, hose 19 9
001925400 Clamp, hose 23 21
001925570 Clamp, hose 21 20
002540080 Tee, branch 29 23
002989380 Weather seal 23 19
008950200 Mounting block, oil cooler 23 22
009039640 Decal - Choke 55 17
009114340 Decal - Diesel 55 2
0840352 Element, air filter 11 9
1000480 Housing, bearing 73 19
1000480 Bearing Housing 69 21
1000770 Roller, Rear 71 17
1000997 Decal 77 25
1000997 Decal, Warning 69 3
1002225 Bolt, roller mounting 77 16
1002228 Bolt, roller mounting 77 16
1002560 Vertical mower 73 24
1002767 Brace, shield 77 27
1002768 Brace, shield 77 28
1003467 Seal 73 10
1004756 Housing, bearing 73 5
1004756 Bearing Housing 69 5
102024 Scraper, front roller 75 11
102024 Scraper blade assembly 81 7
102030 Shaft, front roller assembly 81 2
131161 Assembly, shaft and collar 73 25
131426 Roller, smooth (steel) 81 1
132214 Cover, belt housing 85 7
148231 Fifting, 3/16, elbow 15 50
15531-72-403 Bottle, overflow 9 25
158056-02 Tee, run 31 22
158059-03 Fitting, adaptor, 45 27 14
158059-03 Fitting, adaptor, 45 29 14
158122 Tubing, polyurethane, 13 20
162916 Roller, Rear 71 26
162916 Roller, rear 75 1
162917 Roller, front 75 20
163776 Pulley assembly 83 23
163892 seal 69 29
16676-72-061 Radiator 9 26
198057 Seat 53 1
198059 Arm Rest (left) 53 13
198066 Arm Rest (right) 53 14
2000065 Casting, counterweight 75 8
2000065 Casting, Counterweight 71 6
2000088 Block, pivot 87 9
2188147 Brake, complete, LEFT 51 29
2188147-01 Bracket 51 30
2188147-02 Brake pad-cam 51 31
2188147-03 Pad-support 51 32
2188147-04 Spring-lever retainer 51 33
2188147-05 Housing 51 34
2188147-06 Cam, LEFT 51 35
2188147-07 Pin, pivot 51 36
2188147-08 Brake pad-carrier side 51 37
2188147-09 Pad-support 51 38
2196054 Arm Rest Set (accessory) 53 12
220302 Housing, belt 85 2
2208047 Valve, 4 way 3 position 27 28
2208099 Switch 47 2
2208099 Switch 61 41
2208099 Switch 63 41
2208146 Valve, reel drive 27 29
2208146 Valve, reel drive 29 29
241807 Housing, bearing 89 12
241808 Housing, bearing 89 4
241817 Knob, clutch 83 28
2701710 Motor, reel drive 33 38
2701711 Pump, hydraulic 27 24
2701711 Pump, hydraulic 29 24
2701736 Engine, Briggs & Stratton 7 36
2701768.8 Tailpipe 7 7
2701808 Throttle Control & Cable 7 8
2702239 Housing, Coupler & Adaptor 7 11
2702384 Seal, Cooler 7 12
2702424 Hose, hydraulic, 3/4" x 62" 23 6
2702425 Hose, hydraulic, 1/2" x 41" 23 7
271919 Knob, quick adjuster 93 9
2810043 Shield, Reel 71 9
3000010 Adapter, seal 79 6
3000012 Shaft, rear roller 79 1
3000013 Roller, grooved (steel) 79 2
3000026 Seal, grease 79 5
3000394 Roller, grooved (aluminum) 79 2
3000543 Adapter, seal 79 6
3000698 Washer 71 25
3001654 Shaft, Roller 71 18
3001655 ube, Roller 71 19
3001656 Seal 71 20
3001762 Sleeve 71 23
3003969 Pin, pivot 85 16
3003969 Pin, pivot 87 19
3004410 Spacer, medium 77 38
3005108 Knob, micro adjuster 85 22
3005108 Knob, micro adjuster 87 17
3005373.6 Shield, rear grass 75 38
3005515 Spacer, driven assembly .02" 83 22
3005692 Knob, front roller adjusting 75 27
3005692 Knob, Front Roller Adjusting 71 2
3005970 Spacer, long 77 34
3005971 Spacer, short 77 24
3007975 Bracket, bearing housing 77 1
3008039 Nut, eccentric adjusting 77 15
3008438 Bracket, roller 75 32
3008438 Roller Bracket, Right Side 71 15
3008439 Bracket, roller 75 33
3008439 Roller Bracket, Left Side 71 16
3009138 Screw, 1/4-20 x 1/2 Flat Head 69 16
300983 Seal 71 22
3009922.6 Shield, front grass 75 37
3010293 Stop, Mower 69 11
3010293 Stop, mower 73 14
3010708 Bracket, groomer roller 85 1
3010708 Bracket, groomer roller 87 1
303558 Bearing 71 30
303558 Bearing 75 5
303558 Bearing 75 24
303558 Bearing 81 4
305114 Shaft 75 22
305115 Seal 71 31
305115 Seal 75 6
305115 Seal 75 25
305115 Seal 81 5
315298 Bolt, wheel 79 2
323016 Plug, pipe, 1/8 NPT, 905 87 15
335449 Blade 73 26
336962 Seal, grease 73 7
336962 Seal, grease 73 21
336962 Seal, grease 89 7
336962 Seal, grease 89 15
336962 Seal, Grease 69 7
336962 Seal, Grease 69 23
337370 Coupling, drive 73 36
338748 Bracket, groomer mounting 87 2
338752 Seal, oil 85 8
338758 Pulley, reel shaft 77 18
338763 Seal 77 5
338768 Seal, grease 83 24
338772 Shaft, roller 91 3
338773 Seal, grease 91 4
340780 Brush replacement 77 13A
340836 Pulley, brush shaft 77 10
343616 Stud 75 19
