Jacobsen G-Plex III Parts And Maintenance Manual

97
NUMERICAL INDEX
PART NO DESCRIPTION PAGE ITEM PART NO DESCRIPTION PAGE ITEM
JACOBSEN G PLEX III Series: DN & DP
MAINTENANCE AND PARTS MANUAL
343616 Stud 71 13
345369 Shaft, Roller 71 28
345369 Shaft 75 3
345556 Key, 1/8 x 1/8 x 31/32" 89 18
351520 Clip 75 10
351521 Rod 75 35
351522 Scraper 75 39
351526 Retainer, scraper 75 40
351738 Decal, caution 73 3
352221 Spacer, blade 73 27
352437 Nut, blade clamp 73 28
361877 Decal, danger 73 2
361877 Decal, Danger 69 2
363016 Key, 1/8 x 1/8 x 1/2", parallel 77 11
363818 Spring 77 7
363841 Washer 83 29
364040 Shim, groomer shaft 89 23
364061 Bracket, adjusting pivot 85 27
364061 Bracket, adjusting pivot 87 7
364120 Belt 77 23
364124 Bracket 77 37
364135 Bearing, double row 79 1
364900 Nut, Reel 69 27
365226 Plate, cover 83 1
365227 Pulley, 16 groove 89 17
365228 Pulley, 28 groove 83 2
365229 Bearing w/seal 77 4
365229 Bearing, ball 83 3
365229 Bearing, ball 89 5
365229 Bearing, ball 89 13
365230 Blade (1/4" spacing) 89 21
365232 Spacer 83 5
365233 Link, roller adjusting 85 30
365233 Link, roller adjusting 87 4
365234 Spacer, 1 1/16 x 15/32" 89 20
365234 Spacer, 1/2" spacing 89 26
365235 Belt, drive 83 37
365236 Spacer, 1/4" spacing 89 26
365237 Spacer, grass catcher 83 10
365239 Key, 1/8 x 1/8 x 7/16" 83 7
365240 Decal, turf groomer 83 18
365246 Bolt, Shoulder 69 33
365246 Bolt, shoulder 73 31
365246 Bolt, 3/8-16, nyloc shoulder 83 15
365247 End, rod 85 12
365247 Rod end 87 10
365254 Shaft, stub 83 27
365256 Spacer, pulley 83 6
365257 Bolt 83 31
365258 Pin 83 26
365260 Link, belt adjusting 85 3
365265 Link, adjusting 93 2
365266 Bolt, adjusting 93 6
365267 Plunger 93 5
365268 Spring 93 4
365269 Spring 93 7
365270 Bolt, micro adjusting 85 15
365270 Bolt, micro adjusting 87 12
365271 Bolt 93 3
365272 Spring 83 25
365291 Spring 85 18
365291 Spring 87 14
365293 Spacer, 9/64" long 77 14
365294 Spacer, 1 1/8" long 77 12
365295 Spacer, 27/32" long 77 22
365302 Spacer, pulley 77 22
365330 Bearing, ball 91 2
365341 Washer, special 83 16
365343 Guide, wheel 83 19
365344 Clamp, housing retaining 85 28
365345 Ring, nylos 91 10
365409 Spacer, roller 83 21
367161  Spacer, 1 x 3/4" 89 24
367162 Eccentric, belt adjusting 85 4
367163 Spacer, 7/8 x 7/8" 89 16
367164 Spacer, 7/8 x 1 13/16" 89 8
367164 Spacer 69 13
367165 Spacer, 7/8 x 17/32" 89 2
367166 Cam 85 23
367166 Cam 87 21
379050522 Trim, push-on, 12' (3.6M) 23 17
390857 Shaft, groomer 89 19
390899 Tube, roller, 1/4" spacing 91 1
390900 Tube, roller, 1/2" spacing 91 1
4115061 Pedal, direction control 47 30
4115431 Motor, hydraulic HOS 35 29
4116522 Pawl Latch 51 40
4117098 Muffler 7 6
4118010 Wear Plate 51 39
4119002 Crinkle Washer, M12 51 44
4121789 Valve, Bi-directional, Relief 31 27
4123550 Angle, Cover 23 4
4123563 Angle, screen 23 5
4123564 Rear Engine Bracket 7 4
4123565 Cover, air intake 23 2
4123566 Engine Mount Plate 7 5
4123644 Spacer 5 5
4123645 Bracket, instrument 57 28
4123645 Bracket, instrument 59 28
4123646 Muffler Bracket 5 19
4123664 Housing, oil cooler 23 3
4123676 Heat Shield 7 13
4123773 Muffler Shield 7 9
4123903 Harness, Complete 59 42*
4123904 Harness, 59 42.1*
4123905 Harness, 59 42.2*
4123912 Decal - G-Plex III with Swoosh 55 16
4123940 Panel, instrument (GASOLINE) 59 30
4123970 Clamp 7 29
4124005 Decal,Steering Wheel. 39 17
4124005 Decal - Jacobsen 55 22
4124007 Decal - Jacobsen 55 3
4124157 Wire, red, battery to starter 59 39
4124159 Wire, black ground chassis 59 36
4124161 Starter Solenoid 63 12
4124172 Hose, hydraulic 29 27
4124173 Tube 29 19
4124175 Muffler Guard 5 18
4124180 Manifold 5 1
4124181 Muffler 5 12
4124182 Decal - Jacobsen 55 23
4124190 Decal - G-plex III 55 7
4124217 Panel, instrument (DIESEL) 57 30
4124349 Adaptor, elbow, 90 29 15
4124496 Gasket 5 6
4124765 Wire, black ground engine 57 36
4124765 Wire, black ground engine 59 41
4125159 Seal Kit 31 *
4126343 Nuetral Stop 25 21
4136798 Filter, hydraulic 27 6
4136798 Filter, hydraulic 29 6
4136798 Filter, hydraulic oil 35 8
471240 Fitting, vent 73 23
471240 Vent Fitting 69 25
471514 Fitting, grease, 1/4-28 77 2
48310 Bushing 15 51
5000415 Bedknife Backing 69 14
5000625 Bearing 71 21
5001067 Shield, belt 77 26
5001099 9 Blade Reel 67038 Only 69 4
5001101 11 Blade Reel 67024 Only 69 4
5001182 Filter, fuel 17 10
5002151 Spring, Compression 69 26
5002463 Brush assembly 77 13
