Jacobsen G-Plex III Parts And Maintenance Manual

98
NUMERICAL INDEX
PART NO DESCRIPTION PAGE ITEMPART NO DESCRIPTION PAGE ITEM
JACOBSEN G PLEX III Series: DN & DP
MAINTENANCE AND PARTS MANUAL
5002577 Frame, reel 73 1
5002771 Bedknife, Fairway 69 15
5002814 Tube, Roller 71 27
5002814 Tube, roller 75 2
5003053 7 Blade Reel 67037 Only 69 4
5003577 Frame, Reel 69 1
500534 Bearing, cup and cone 73 6
500534 Bearing, cup and cone 73 20
500534 Bearing, Cup and Cone 69 6
500534 Bearing, Cup and Cone 69 22
503378 Bearing, ball, cup and cone 79 3
515268 Bushing 49 5
517163 Spacer, rubber 43 11
522840 Washer, thrust 43 13
523126 Bumper, rubber 41 12
523126 Bumper, rubber 43 14
523213 Clip 9 10
523221 Spacer 49 6
523224 Bumper, rubber 53 3
523253 End, control rod 25 15
523253 End 51 10
523356 Adjuster, seat wihandle (left) 53 4
523357 Adjuster seat (right) 53 5
523409 Knob 25 16
523492 Bushing 25 37
523768 Adapter, elbow 90 21 19
523768 Adapter, elbow 90° 23 12
523768 Adaptor, elbow, 90° 35 11
523930 Foam 9 33
524215 Bushing,turf guard 43 15
547610 Cable, control (throttle) 5 31
547818 Head, hydraulic filter 27 7
547818 Head, hydraulic filter 29 7
547818 Head,filter 35 12
590002786 Bushing 41 11
590002786 Bushing 43 12
64061-26 Pin, spirol, 1/4" 41 9
64061-26 Pin,spirol,1/4" x 1 3/4" 43 10
64220-01 Wheel Bolt 1/2" 65 20*
680001941 Tie,cable 33 3
680001941 Tie,cable, 37 6
800810 Ring, internal retaining 33 47
800810 Ring, retaining, internal 67 1
810149 Bumper, rubber 9 18
810152 Cover, footpedal 51 17
810722 Yoke 51 18
814065 Choke Cable (152cm) 7 30
814499 Spring, compression 41 20
814924 Clamp, hose 33 9
815058 Clamp 9 12
817320 Clamp 17 20
820529 Spacer 13 27
821893 Trim, push-on, 12' (3.6M) As 9 14
821893 Trim, pushon, 12(3.7 M) 13 18
822474 Spacer 95 3
823332 Bushing 51 19
823332 Spacer 51 41
823332 Bushing 53 9
826000 Fuse, 20 amp 57 50
826000 Fuse, 20 amp 59 50
826000 Fuse, 20 amp 61 2
826000 Fuse, 20 amp 63 2
826218 Mount, motor 5 17
826218 Motor Mount 7 33
827320 Arm, spring retainer 25 41
827821 Knob, ball 5 33
827821 Ball Knob 7 34
829500 Spring, extension 49 15
829726 Trim, push on, 12' 51 20
829954 Gasket 17 11
829954 Gasket 19 4
830355 Weatherseal, 35' (1 0.6M). As 9 15
831518 Ball Joint 25 22
831518 Ball Joint 47 27
831586 Ball Joint 25 23
831877 Bushing 37 11
832499 Bearing, ball, 1" ID 2" OD 43 27
833038 Fuse, 30 amp 57 51
833038 Fuse, 30 amp 59 51
833038 Fuse, 30 amp 61 7
833038 Fuse, 30 amp 63 7
833851 Seal 53 10
834037 Connector, hose 19 14
835039 Fastener, snap 23 20
835805 Hose, overflow 4' (1 .2M) . As 9 17
836206 Clamp 15 52
836621 Seal, oil 65 8
836719 Nut, bearing adj 65 9
836852 Breather 13 32
837298 Spacer 61 11
837298 Spacer 63 11
837462 Boot, battery terminal 61 39
837462 Boot, battery terminal 63 39
837735 Plate,twinweld 33 10
837735 Plate, twin weld, M8 35 14
837736 Plate, clamp cover 31 11
837736 Plate, clamp cover 33 11
837736 Plate,clamp cover 35 15
837737 Set, clamp, hydraulic 35 16
837753 Adaptor, elbow, 90° 35 17
838093 Rod, threaded, 5/16-24 x 2 1/2".. 25 24
838154 Bracket,fuelpumpmount 17 12
838225 Clip 13 33
838363 Decal - Throttle 55 13
838367 Decal - Parking Brake P 55 14
838476 Latch, draw 43 28
838491 Cap, fuel line 19 7
839063 Bearing, ball, 5/8" ID 1 3/8" OD 43 29
839072 Catcher, grass 95 4
839181 Pin, rodconnecting,threaded 41 22
839391 Clamp, battery 3 20
839388 Bracket, pivot mounting 47 29
839410 Bushing, spring stop 43 30
839556 Fitting, adaptor, straight 27 12
839556 Fitting, adaptor, straight 29 12
839557 Fitting, adaptor, 90 27 13
839557 Fitting, adaptor, 90 29 13
839557 Fitting, adaptor, elbow, 90° 35 19
839721 Cover, steering unit, lower 39 11
839807 Adapter, straight 21 21
839807 Adapter, straight 23 23
839814 Hose, hyd. 1/2" i.d. x 38" 33 13
839820 Adaptor, elbow, 90 27 16
839820 Adaptor, elbow, 90 29 16
839821 Adapter, elbow 90° 23 24
839837 Hose, hydr. 1/4" i.d. x 10 1/2" 31 15
839841 Hose, hydraulic, 1/4" i.d. x 70" 37 17
839842 Hose, hydraulic, 1/4" i.d. x77" 37 18
839846 Fitting, adaptor, 45° 37 19
839860.06 Bracket,mountingcover 39 13
839876 Bushing 13 35
839953 Hose, radiator, bottom 9 20
839973.07 Panel, screen 9 21
839975.06 Bracket, mounting, fuel filter 17 13
840002-1 Timer, Fuel shut off 57 47
840003 Tread, control pedal 47 10
840017 Cover,steeringwheel 39 16
840062.07 Panel, radiator 9 22
840065 Decal - Speed Ctrl 55 4
840085.06 Stop, reel 43 31
840161 Element, fuel filter 17 19
840170.07 Box, tool/step 3 21
840171.07 Cover,box 3 22
840172 Hinge, box 3 23
