Jacobsen G-Plex III Parts And Maintenance Manual

99
NUMERICAL INDEX
PART NO DESCRIPTION PAGE ITEM PART NO DESCRIPTION PAGE ITEM
JACOBSEN G PLEX III Series: DN & DP
MAINTENANCE AND PARTS MANUAL
840192 Sleeve, nylon 3" x 16" 37 20
840344 Bushing 43 32
840346 Adaptor, gauge 11 5
840347 Hood, inlet 11 6
840420 Plate, latch 51 22
840476 Spring 25 42
840507 Pin, lift cylinder pivot 41 23
841160.06 Bracket, radiator 9 1
841203 Pin, rod connecting 41 24
841466.06 Bracket, bumper-front 41 25
841487 Angle, lockout link 49 16
841522 Disk, orifice 31 17
841673 Hose, hyd. 1/2" i.d. x 34" 33 15
841676 Hose, hydraulic, 1/4" i.d. x 30" 37 21
841700 Adaptor, elbow, 90° 31 18
841741 Cap, pivotshaft 41 26
841741 Cap 43 33
841895 Cover, Battery Terminal 57 26
841895 Cover, Battery Terminal 59 26
842401 Latch 41 38
842401 Latch 45 48
842402 Rivet 41 39
842402 Rivet 45 49
842403 Handle 41 40
842403 Handle 45 50
842471 Rod, Threaded, 3/8 - 24 41 28
842539.06 Bracket, engine mount 5 21
842540.06 Bracket, engine rear 5 22
842598 Spring, extension 51 24
842830 Hose, hyd. 1/4" i.d. x 22" 33 17
842880.07 Panel, floor, RIGHT 3 25
842882.06 Panel, line cover 3 27
842916 Cooler, oil 21 18
842916 Cooler, oil 23 25
842933 .06 Panel,seatbase 53 11
842932.06 Panel, control 3 29
842999 Cable, control 25 25
842999 Cable, direction control 47 31
843117 Arm,control 25 44
843119.06 Bracket,pumpcontrol 25 26
843160 Hub,wheel&disc 51 25
843181 Spacer, bearing 43 35
843185 Bushing, pivot 43 36
843195 Spacer, bearing 43 37
843196.06 Bracket, lift valve 3 30
843412 Bracket, Switch mounting 3 33
843252 Rod,threaded 5/16-24 51 26
843267 Tank, fuel 13 37
843267 Tank, fuel 17 14
843267 Tank, fuel 19 1
843268 Reservoir, oil 13 38
843401 Cap, fuel with gauge 13 39
843401 Cap, fuel wigauge 17 15
843401 Cap, fuel with gauge 19 2
843402.07 Cover, battery 3 31
843411 Lever, valve 27 19
843556 Elbow, 90, 11/16 x 1/2 NPT 15 47
843557 Elbow, 90, 3/4 x 3/4 NPT 15 48
843558 Elbow, 90, 1 x 1 NPT 15 49
843612.07 Housing, instrument 57 27
843612.07 Housing, instrument 59 27
843886 Cover 3 34
843887.07 Strap, cover 3 35
843696 Tube, support, 8 (203 mm) 13 40
843816 Diode Circuit Board 61 *
843816 Diode Circuit Board 63 *
843821 Pin,cylinder pivot 41 29
843821 Pin,cylinderpivot 43 38
843823 Screen, cooler 23 26
843885 Plug 13 41
843908 Hose, hydraulic 1/4 ID x 10 5/8" 31 19
843909 Hose, hyd. 1/4" i.d. x 40 1/2" 33 18
843910 Hose, hyd. 1/4" i.d. x 49" 33 19
843911 Hose, hyd. 1/4" i.d. x 47 1/2" 33 20
843912 Hose, hydraulic, 3/8" i.d. x 22" 37 23
843913 Hose, hyd. 1/4" i.d. x 76" 33 21
843914 Hose, hydraulic, 3/4" i.d. x 17" 35 21
843915 Union,bhead450 33 22
843916 Hose, hydraulic 3/8 ID x 39" 31 20
843917 Hose, hydraulic 3/8 ID x 39" 31 21
843919 Hose, hydraulic, 1/4" i.d. x 72 1" 37 25
843920 Hose, hydraulic, 1/4" i.d. x 60 5/ 37 26
843921 Hose, hyd. 1/2" i.d. x 47 1/2" 33 23
843922 Hose, hyd. 1/2" i.d. x 43 1/4" 33 24
843923 Hose, hyd. 1/2" i.d. x 28" 27 20
843923 Hose, hyd. 1/2" i.d. x 28" 29 20
843925 Hose, hydraulic, 1/2" id x 53" 21 26
843926 Hose, hydraulic, 1/2" i.d. x 16 3" 35 22
843927 Hose, hydraulic, 1/2" i.d. x 18 1/ 35 23
843928 Hose, hydraulic, 3/4" i.d. x 22 1/ 35 24
843930 Hose, hydraulic, 3/4" id x 66" 21 25
843931 Hose, hyd. 1" i.d. x 15" 27 21
843931 Hose, hyd. 1" i.d. x 15" 29 21
843932 Hose, hyd. 1" i.d. x 26 1/2" 27 22
843932 Hose, hyd. 1" i.d. x 26 1/2" 29 22
843933 Hose, hydraulic, 1" i.d. x 12 3/4" 35 25
843989 Union, male 33 25
843991 Elbow, male 33 26
844044.06 Bracket, air filter 11 11
844045 Hose, air intake 11 4
844071 Tee, branch 27 23
844072 Union, bulkhead 33 28
844076 Strap 3 36
844080 Adapter 13 42
844082 Tee, branch 33 30
844083 Sleeve, nylon, 1 7/8" x 38" 33 31
844084 Sleeve, nylon, 1 7/8" x 43" 33 32
844085 Sleeve, nylon, 1 7/8" x 52" 33 33
844086 Sleeve, nylon 1 7/8" x 12" 37 28
844214 Sleeve, nylon, 1 7/8" x 48" 33 34
844215 Clamp, tube 31 23
844216 Clamp, hose 33 35
844217 Clamp,tube 33 36
844218 Set, clamp 3/8" 31 24
844219 Clamp, tube 3/8" 31 25
844294 Gasket, instrument panel 57 31
844294 Gasket, instrument panel 59 31
844496 Hub 5 25a
844497 Coupling 5 25b
845278 Adaptor, motor 67 6
845278 Adapter, motor 73 37
845279 Seal, o-ring, 1.49 i.d. x 0.7 67 5
845279 Seal, o-ring, 1.49 i.d. x .07 73 38
845280 seal, o-ring, 1.99 i.d. x 0.7 67 5
845280 Seal, o-ring, 1.99 i.d. x .07 73 39
869037 Fitting, 3/4 x 3/4 NPT 15 53
869118.06 Mount, rear frame stop 43 39
886735 Valve Stem 65 17
886802 Gauge, hour meter 61 17
886802 Gauge, hour meter 63 17
887692 End, tie rod 37 29
888036 Gauge, restriction 11 7
888973 Pump,fuel 17 16
889843 AxIe 65 10
889859 Bearing, Assy 65 5
891910 Kit, service 35 *
891910 Kit, service 35 *
892007 Bracket, catcher 95 5
892171.07 Hub 65 11
892175 Pivot, fronthead steering 41 30
892225 Hub & Axle, complete 65 1
892228 Wheel, steering, 14" (356 mm) 39 14
892272 Cylinder, hydraulic 37 31
892381 Motor, hydraulic 35 32
