Jacobsen G-Plex III

101
NUMERICAL INDEX
PART NO DESCRIPTION PAGE ITEM PART NO DESCRIPTION PAGE ITEM
JACOBSEN G PLEX III Series: DN & DP
MAINTENANCE AND PARTS MANUAL
A912175 Hose, fuel, 5/16 17 9
A912176 Hose, radiator, top 9 19
A912182 Hose - Fuel 3/16 17 *
A913552 Gaiter 39 19
A914210 Cover, handle 39 4
A923953 Decal - Footswitch. 55 26
J337370 Coupling, drive 33 46
J337370 Coupling, drive 67 4
J366877 Nylon Bush 47 32
MBE3313C.07 Pad Assy 47 1
MBF0654A CoIler, set, 3/8" 41 10
MBF2020 Switch Bracket 39 23
MBF2047 Switch Handle 39 20
MBG5090A Pod Support 57 53*
MBG5090A Pod Support 59 53*
MBG5293 PawI, lock 51 23
MBG5769 Bracket-Switch 39 24
MBG5770 Hinge Bracket 39 25
MBG6052 Panel, floor, LEFT 3 24
MBG6060 Pin 39 22
MBG6330 Cover,steeringunit,top 39 12
MBG6344 Control Arm 25 35*
MBG6471 Panel, foot, CENTER 3 26
MBG6472 Panel, floor, CENTER 3 28
MBG6994 Bushing 47 28
W148270 Sender,watertemperature 5 24
W158006-01 Adaptor, straight 31 13
W158006-01 Adaptor, straight 37 13
W158006-04 Adapter, straight 31 5
W158006-05 Adaptor, straight 27 18
W158006-05 Adaptor, straight 29 18
W158006-05 Adaptor, straight 33 16
W158006-07 Connector 35 26
W158007-01 Adaptor, elbow 90° 31 12
W158007-01 Adaptor, elbow, 90° 37 12
W158007-02 Adapter,elbow9O0 21 22
W158007-02 Adaptor, elbow, 90 27 17
W158007-02 Adaptor, elbow, 90 29 17
W158007-02 Adaptor, elbow, 900 33 14
W158007-03 Adaptor, elbow, 90 27 15
W158007-05 Adaptor, elbow, 90° 35 9
W158011-01 Tee, union 31 10
W158056-01 Tee, run 35 27
W158058-01 Fitting, adaptor, 900 35 3
W158059-01 Adaptor, 450 27 11
W158059-01 Adaptor, 450 29 11
W158135-01 Switch, seat 57 1
W158135-01 Switch, seat 59 1
W158135-01 Switch, seat 61 1
W158135-01 Switch, seat 63 1
W178079 Fitting,test 27 1
W178079 Fitting,test 29 1
