Jacobsen LF 3400 Safety & Operation Manual

CONTROLS 3
9
!
4131663
4WD
2WD
77
93
110
° C
170
200
230
° F
!
WARNING
1. Read operators manual,
do not allow untrained
operators to use machine.
2. Keep shields in place
and hardware securely
fastened.
3. Before you clean, adjust
or repair this equiptment,
disengage all drives,
engage parking brake
and stop engine.
4. Keep hands, feet and
clothing away from
moving parts.
5. Never carry passengers.
6. Keep bystanders away.
7. Inspect hoses and fabric
covers daily. If worn or
damage, replace with
original quality parts.
8. Do not use on slopes
greater than 22 °.
4131828
Total Hours
1
10
0 0 0 0 0
A Tilt Steering Lever
B1 Parking Brake Lock
B2 Parking Brake Release
C Parking Brake
D
Mow Speed Stop
E Traction Pedal - Forward
F Traction Pedal - Reverse
G
Seat Adjustment
H Hydraulic Oil Cap/Dipstick
I Fuel Cap
J Air Cleaner Indicator
K Backlap Switch
L Alarm
M Controller / Fuses
N Hyd. Oil Level Light
O Hyd. Oil Level / Horn Switch
P Mower Lift Lever
Q Reel Switch
R 2 WD / 4 WD Switch
S Light Switch
T Engine Throttle
U Cruise Control (Option)
V Ignition Switch
W Hour Meter
X Fuel Gauge
Y Warning Lights
Z Engine Coolant
Temperature Gauge
A
B
1
C
B
2
D
E
F
G
N
O
P
Q
R
S
T
U
V
H
I
J
W
X
Y
K
Z
L
M
