87
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
------------ 1 Tray, Battery See 7.1
2 1004776 2 Headlight
5000527 1 • Bulb
5003623 1 • Bracket
> 3 4139095 1 Controller
4 400104 1 Screw, 1/4-20 x 1/2” Hex Head
5 366931 1 Battery
> 6 441668 4 Screw, 5/16-18 x 1-1/4” Hex Head
7 445795 9 Nut, 5/16-18 Spiralock Flange
8 445796 5 Nut, 3/8-16 Spiralock Flange
9 444310 7 Nut, #10-24 Hex
10 446128 1 Lockwasher, 1/4
11 400258 2 Screw, 3/8-16 x 3/4” Hex Head
12 403914 2 Screw, #10-24 x 3/4” Truss Head
> 12 4135546 1 Body Wire Harness 7 Gang Units
555486 1 • 3A Diode
5003276 2 • 3 Amp Fuse
5003282 1 • 20 Amp Fuse
5003283 1 • 25 Amp Fuse
13 361439 1 Circuit Breaker, 12V 50A
14 446118 7 Lockwasher, #10
15 403910 5 Screw, #10-24 x 1/2” Truss Head
> 16 3001307 3 Relay-SPDT With Resistor
17 3006434 1 Switch, Rocker
18 3007777 1 Cable, Positive Battery
19 2810213 1 Cable, Negative Battery
20 473142 1 Cable Tie
21 3009251 1 Tab, Wire Harness
22 409804 3 Screw, #10-32 x 1/2” Thread Cutting
23 3007558 1 Clamp, Double Tube
24 400188 3 Screw, 5/16-18 x 1” Hex Head
25 555406 1 Fuel Filter Assembly Included With Engine
2500809 1 • Fuel Filter Element
2501023 1 • Filter Cover
2501024 1 • Filter Breather Plug
2501025 1 • O-Ring
2501026 1 • Form, Mark
26 367631 4 Spacer
27 345666 1 Clamp, 1/2” I.D.
> 28 453023 1 Flat Washer, 1/4
446128 1 Lockwasher, 1/4
> 29 444708 4 Locknut, 1/4-20 Center
To Next Page
