Jacobsen LF 4677

109
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
443108 4 Locknut, 5/16-18 Center
2 N/S 1 Port Cover
3 C 1 Seal, O-Ring
4 C 4 Seal, O-RIng
5 C 4 Seal, O-RIng
6 443828 1 Nut, 5/8-18 Hex Jam
7 N/S 4 Special Bolt
8 N/S 1 Port Manifold
9 B 3 Spring, Port Side
10 N/S 1 Hex Drive
11 A and E 9 Needle Roller
12 503398 1 Valve Ring
13 503398 1 Valve Plate
14 B 3 Spring, Shaft Side
15 N/S 1 Isolation Manifold
16 N/S 1 Drive Link
17 N/S 1 Metering Ring
18 A 11 Screw, Socket Head
19 C 1 Seal, Commutator
20 A 1 Commutator Cover
21 A 1 Commutator RIng
22 A 1 Commutator
23 A 1 Spacer
24 A 1 Rotor
25 A 1 Stator
26 A 1 Drive Plate
27 554855 1 Spacer
28 554856 1 Thrust Bearing
29 C 1 Face Seal
30 N/S 1 Ball, 9/32”
31 554857 1 Seal, Spacer
32 N/S 1 Upper Cover Plate
33 D 1 Shaft
34 D 1 Retaining RIng
35 D 1 Bushing
36 D 1 Seal
37 D 1 Jacket
38 557733 1 Relief Valve Cartridge
Service Kits
A 5003220 1 Metering Assembly Kit
B 502924 1 Spring Kit
C 557738 1 Seal Kit
D 5003219 1 Jacket Tube Kit
E 502925 1 Needle Roller Kit
