39
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
1004279 1 Bottom, Toolbox
2 3009292 1 Seat Pan
3 400258 9 Screw, 3/8-16 x 3/4” Hex Head
4 400184 8 Screw, 3/8-16 Spiralock Flange
5 445795 18 Nut, 5/16-18 Spiralock Flange
6 446142 9 Lockwasher, 3/8 Heavy
7 452008 9 Flat Washer, 3/8
8 4145565 1 Platform Includes Items 6 - 8, Illustration 1.1
9 3007609 1 • Pad, Left Floorboard
10 3007610 1 • Pad, Right Floorboard
11 3007611 1 • Pad, Left Foot
12 3007612 1 • Pad, Right Foot
13 315387 1 Grommet
14 3003928 1 Pouch, Literature
15 404118 4 Screw, 3/8-16 x 7/8” Truss Head
16 5003191 1 Floorboard
17 3007608 1 • Pad, Center Floorboard
18 3008218 1 Cover, Hydro
19 404016 2 Screw, 1/4-20 x 5/8” Truss Head
20 445245 2 Tinnerman Nut
> 21 4139433 1 Seat Assembly Suspension
> 4139436 1 • Arm Rest Kit
> 4139434 1 • • Left Arm Rest Kit
> 4139435 1 • • Right Arm Rest Kit
> 4139450 1 • Switch Seat
> 4139437 1 • Seat Belt Kit
> 22 4131137 1 Adjuster Assembly
> 23 4139241 1 Bracket Assembly Seat Support
> 24 4129237 1 Plate, Cover
> 25 409812 4 Screw, 5/16-18 x 3/4 THD Cut
> 26 452004 2 Flat washer, 1/4
> 27 800943 2 T-Screw #10-16 x 3/4 BS BR Plastic
> 28 831053 4 Spacer, Seat
