43
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
1003288 1 Treadle Pivot
2 352726 2 • Bushing
3 3007230 1 Stop, Mow Speed
4 3003474 1 Grip, Pedal
5 3003475 1 Grip, Pedal
6 366974 2 Rod End
7 3007392 1 Switch, Proximity
8 3006327 1 Shaft, Turn Assist
9 333542 1 Tie Stud
10 3006998 1 Rod, Hydro
> 11 3006999.7 1 Bracket, Hydro Mount
12 3007001 1 Pedal, Hydro
> 13 471216 1 Fitting, Grease 1/4-28
14 446136 2 Lockwasher, 5/16 Heavy
15 446110 2 Lockwasher, #8
16 403860 2 Screw, #8-32 x 5/8” Truss Head
17 453004 2 Flat Washer, #8
18 444718 1 Locknut, 5/16-18 Center
19 400272 1 Screw, 3/8-16 x 2-1/4” Hex Head
20 445795 6 Nut, 5/16-18 Spiralock Flange
21 400182 4 Screw, 5/16-18 x 5/8” Hex Head
22 443112 2 Nut, 3/8-24 Hex
23 452008 2 Flat Washer, 3/8
24 444306 2 Nut, #8-32 Hex
25 3002695 1 Washer
26 400188 7 Screw, 5/16-18 x 1” Hex Head
27 445796 6 Nut, 3/8-16 Spiralock Flange
28 400264 2 Screw, 3/8-16 x 1-1/4” Hex Head
29 3008383 1 Clip, Wire Harness
30 3009193 AR Shim, Switch
To Next Page
