Jacobsen LF 4677 Maintenance Manual

47
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
5002573 2 Tire
2 5002574 2 Rim
3 360111 2 Valve, Inflation
4 1001757 2 Wheel Motor See 40.1
5 557623 2 • Key
6 557624 2 • Nut, Hex
7 2812246 1 Frame Includes Four (4) of Item 10
8 366871 2 • Bushing
9 1002853 1 Front Axle Includes Six (6) of Item 10
10 366870 10 • Bushing
11 – 1 Brake Assembly See 38.1
12 – 1 Brake Assembly See 38.1
13 2000141 2 Hub, Wheel
14 319212 2 Spring, Extension
15 340486 2 Disk Brake
16 446154 8 Lockwasher, 1/2 Heavy
17 400410 8 Screw, 1/2-13 x 1-3/4” Hex Head
18 353914 12 Wheel Bolt
19 400108 16 Screw, 1/4-20 x 3/4” Hex Head
20 4113047 4 Screw, 5/8-18 x 1-1/2” Hex Head Grade 8 Bolt
21 409811 1 Screw, 5/16-18 x 5/8” Thread Cutting
> 22 443128 4 Nut< Hex 5/8-18 UNF
> 23 452016 8 Flat Washer, 5/8 x 175 x .688
24 460093 2 Cotter Pin, 1/8 x 2-1/2”
25 1003047 1 Cable, Right Brake
26 1003048 1 Cable, Left Brake
27 557771 2 • Clip, Brake Cable
28 461493 2 Clevis Pin, 5/16 x 3/4”
29 460014 2 Cotter Pin, 3/32 x 3/4”
30 3007970 2 Seal, Tube
31 3008193 2 Retainer, Seal
32 409804 6 Screw, 1/4-20 x 5/8” Thread Cutting
33 345666 1 Clamp
34 445795 5 Nut, 5/16-18 Spiralock Flange
> 35 441602 4 Bolt, 5/16-18 x 3/4” Carriage
36 4103060 1 Battery Tray
37 2810553 1 Clamp, Battery
38 4103061 1 Bracket, Fuel Filter
39 400188 1 Screw, 5/16-18 x 1” Hex Head
40 400258 1 Screw, 3/8-16 x 3/4” Hex Head
41 446142 1 Lockwasher, 3/8 Heavy
> 42 4140094 6 Washer .688 x 1.313 x .150 HAR
