SPECIFICATIONS 2
en-11
2.8 VIBRATION LEVEL_________________________________________________________
When the machine was tested for hand/arm vibration levels, the operator was standing in the normal operating position
with both hands on the handle. The engine was running and the cutting device was rotating with the machine
stationary.
The Machinery Safety Directive 2006/42/EC
By compliance to:
The Lawnmower Standard EN836:1997
Referenced to Hand/Arm: BS EN ISO20643:2008
Information Supplied for Physical Agents Directive 2002/44/EC
By reference to:
Hand/Arm Standards: BS EN ISO 5349-1 (2001)
BS EN ISO 5349-2 (2001)
PGM 22
Hand/Arm
Acceleration
Level
63280 PGM 22, 11 Blade 63286 PGM 22, 15 Blade
Maximum Left Hand or Right Hand Accelerations m/s
2
Mean Value of X, Y, Z Aeq
8.237 ± 1.3 5.63 ± 1.3
