This manual contains safety, operating, adjustment,
maintenance, troubleshooting instructions and parts list
for your new Jacobsen machine. This manual should be
stored with the equipment for reference during operation.
Before you operate your machine, you and each operator
you employ should read the manual carefully in its
entirety. By following the safety, operating and
maintenance instructions, you will prolong the life of your
equipment and maintain its maximum efficiency.
If additional information is needed, contact your
Jacobsen Dealer.
The serial plate is located on the rear crossbar of the
frame. Jacobsen recommends you record these numbers
below for easy reference.
11524 WILMAR BLVD,
CHARLOTTE, NC 28273
®
kg kW
1-800-848-1636 (US)
PRODUCT OF U.S.A.
A Textron Company
en-2
Proposition 65 Warning
This product contains or emits
chemicals known to State of California
to cause cancer and birth defects or
other reproductive harm.
FOREWORD
Suggested Stocking Guide
To Keep your Equipment fully operational and productive, Jacobsen suggests you maintain a stock of the more
commonly used maintenance items. We have included part numbers for additional support materials and training aids.
To order any of the following material:
1. Write your full name and complete address on your
order form.
2. Explain where and how to make shipment:
❑ UPS ❑ Regular Mail
❑ Overnight ❑ 2nd Day
3. Order by the quantity desired, the part number, and
the description of the part.
4. Send or bring the order to your authorized Jacobsen
Dealer.
LITHO IN U.S.A. 6-2013
Service Parts
Service Support Material
Qty. Part No. Description Qty. Part No. Description
5002605 11 Blade Reel 164056 Brake Band
503477 22” High Profile Bedknife 366648 Seal, Grease
503478 22” Low Profile Bedknife 3006511 Washer
503479 22” Tournament Bedknife 337677 Seal, Oil
5002887 22” Super Tournament Bedknife
Qty. Part No. Description
4131595 Technical Manual
4191633 Operator Training Video
4171663 Service Manual
Qty. Part No. Description
These are the original instructions verified by
Jacobsen, A Textron Company.
