37
> Change from previous revision
PGM
Item Part No. Qty. Description Serial Numbers/Notes
●▲
1
207480 1 Cover, Chain
2 472201 1 Plug, 1/8 Pipe,Square Head
◆ 3 400102 1 Screw, 1/4-20 x 3/8” Hex Head
4 446130 4 Lockwasher, 1/4 Heavy
5 304756 1 Retainer
6 503438 1 Lever, Shift
7 339910 1 • O-Ring
◆ 8 403528 2 Screw, #8-32 x 3/8” Hex Head
9 446110 2 Lockwasher, #8 Medium
10 304758 1 Cover
11 304757 1 Gasket
◆ 12 434041 4 Screw, 1/4-20 x 3/4” Flat Soc Hd
13 1001309 1 Bracket, L.H. Brake Mounting
14 313777 1 Seal, Oil
●▲ 15 3002906.7 1 Housing, Bearing
16 303566 1 Bearing
17 304747 1 Gasket
◆ 18 434043 3 Screw, 1/4-20 x 2-1/4” Socket Head
◆ 19 434042 5 Screw, 1/4-20 x 1-1/2” Socket Head
20 3006511 5 Washer
Required for proper sealing of Left Side Frame
● 473194 AR Loctite Primer 6 oz Aerosol Can
▲ 473195 AR Loctite 518 Gasket Eliminator 15 oz cartridge
◆ 473130 AR Loctite 242 (Blue)
