73
> Change from previous revision
R-311T
Item Part No. Qty. Description Serial Numbers/Notes
1
4207484 2 Mount, Rear Engine
2 358794 4 Washer
3 4207482 1 Mount, Left Front Engine
4 4207483 1 Mount, Right Front Engine
5 365979 7 Screw, M12-1.25 x 25 mm Metric Grade 8.8
6 446154 7 Lockwasher, 1/2 Heavy
7 453017 7 Flat Washer, 1/2
8 362263 1 Screw, M10-1.25 x 25 mm Metric Grade 8.8
9 363485 1 Lockwasher, M10
10 453013 1 Flat Washer, 7/16
11 365981 4 Screw, M14-1.5 x 25 mm Metric Grade 8.8
12 446160 4 Lockwasher, 9/16 Heavy
13 400190 4 Screw, 5/16-18 x 1-1/4” Hex Head
14 446142 8 Lockwasher, 3/8 Heavy
15 445795 8 Nut, 5/16-18 Spiralock Flange
16 400276 4 Screw, 3/8-16 x 3” Hex Head
17 4209701 2 Isolator, Engine
18 367031 4 Washer, Isolator
19 4209700 2 Isolator, Engine
20 443110 4 Nut, 3/8-16 Hex
To Next Page
