53
> Change from previous revision
R-311T
Item Part No. Qty. Description Serial Numbers/Notes
1
4116048 1 Pedal, Hydro
2 3007230 1 Stop, Mow Speed
3 3003474 1 Grip, Reverse Pedal
4 3003475 1 Grip, Forward Pedal
5 400188 1 Screw, 5/16-18 x 1” Hex Head
6 3002695 1 Flat Washer, 5/16
7 444718 1 Locknut, 5/16-18 Center
8 4183720 1 Arm, Pedal
9 409812 2 Screw, 5/16-18 x 3/4” Thread Cutting
10 4224560 1 Bracket, Pedal Support
11 366877 2 Bearing, Nylon
12 400146 1 Screw, 1/4-28 x 3/4” Hex Head
13 446130 1 Lockwasher, 1/4 Heavy
14 453023 1 Flat Washer, 1/4
15 441602 2 Carriage Bolt, 5/16-18 x 3/4”
16 445781 2 Nut, 5/16-18 Whizlock Flange
17 1000649 1 Switch, Reverse Sensing REFERENCE SW23, See 62.1
18 403746 2 Screw, #10-24 x 3/4” Hex Head
19 64251-001 6 Flat Washer, #10
20 446116 2 Lockwasher, #10
21 444310 2 Nut, #10-24 Hex
22 400272 2 Screw, 3/8-16 x 2-1/4” Hex Head
23 445796 4 Nut, 3/8-16 Spiralock Flange
24 4185902 AR Shim, Switch
25 455066 AR Washers, 1/4”
26 4140149 1 Switch, Neutral Start REFERENCE SW24, See 62.1
27 4182720 1 Guard, Switch
28 3009193 AR Shim, Switch
29 402066 2 Screw, #8-32 x 1” Hex Head
30 446110 2 Lockwasher, #8
31 444306 2 Nut, #8-32 Hex
To Next Page
