R-311T
Item Part No. Qty. Description Serial Numbers/Notes
1
4183261 1 Brake Pedal
2 352726 2 • Bushing
3 3006327 1 Shaft, Brake Pedal
4 4100460 2 Arm, Brake
5 403770 2 Screw, 5/16-18 x 3/4” Hex Flange
6 4183260 1 Lever, Parking Brake
7 400190 1 Screw, 5/16-18 x 1-1/4 Hex Head
8 453009 2 Flat Washer, 5/16
9 3007941 1 Spacer
10 3007942 1 Spring, Torsion
11 3002695 1 Flat Washer, 5/16
12 444718 1 Locknut, 5/16-18 Center
13 4217460 1 Bracket, Cruise Control Switch
14 1000649 1 Switch, Cruise Control Cut-out REFERENCE SW21, See 62.1
15 403860 2 Screw, #8-32 x 5/8” Truss Head
16 453004 4 Flat Washer, #8
17 446110 4 Lockwasher, #8
18 444306 4 Nut, #8-32 Hex
19 3003475 1 Grip, Pedal
20 4207861 2 Screw, #8-32 x 3/4” Flat Head
21 471217 1 Fitting, 5/16 Straight
22 441602 4 Carriage Bolt, 5/16-18 x 3/4”
23 445781 4 Nut, 5/16-18 Hex Flange
24 362744 2 U-Bolt
25 446134 5 Lockwasher, 5/16
26 443806 8 Nut, 5/16-18 Hex Jam
27 4108161 2 Spring, Brake
28 461451 2 Clevis Pin, 5/16 x 15/16”
29 460014 4 Cotter Pin, 3/32 x 3/4”
30 4213263 2 Cable, Brake
31 443812 2 Nut, 3/8-24 Hex Jam
32 4213262 2 Link, Chain
33 1000649 1 Switch, Parking Brake REFERENCE SW2, See 62.1
34 443106 1 Nut, 5/16-18 Hex
35 4213480 1 Floor Support
36 4185902 1 Shim, Switch
37 461493 2 Clevis Pin, 5/16 x 3/4”
38 REF 1 Brake Caliper Assembly See 14.1
39 400186 1 Screw, 5/16-18 x 7/8” Hex Head
To Next Page
