4 CONTROLS
11
4.2.4 FRONT DECK LEVER ______________________________________________________
The front deck lever lifts and lowers the front deck.
Press and release the lever until the front deck has lowered to the ground. If the PTO
switch is in the ON position, the front deck blades will start to turn when the front deck
is lowered.
Pull and hold the lever until the front deck has lifted. When the front deck is lifted, the
front deck blades will stop.
4.2.5 LEFT WING DECK LEVER __________________________________________________
The left wing deck lever lifts and lowers the left wing deck.
Press and hold the lever until the left wing deck has lowered to the ground. If the PTO
switch is in the ON position, the left wing deck blades will start to turn when the left
wing deck is lowered.
Pull and hold the lever until the left wing deck has lifted. When the left wing deck is lifted, the left wing deck blades will
stop.
4.2.6 RIGHT WING DECK LEVER _________________________________________________
The right wing deck lever is for lift and lower the front deck.
Press and hold the lever until the right wing deck has lowered to the ground. If the
PTO switch is in the ON position, the right wing deck blades will start to turn when the
right wing deck is lowered.
Pull and hold the lever until the right wing deck has lifted. When the right wing deck is lifted, the right wing deck blades
will stop.
NOTICE
The engine throttle must be at least 50% speed to lift or lower the decks.
NOTICE
To prevent damage to the mower, make sure that the left wing transport latch is
disengaged before you lower the left wing deck. See 4.7
NOTICE
To prevent damage to the mower, make sure that the right wing transport latch is
disengaged before you lower the right wing deck. See 4.7
